(This product is discontinued.) The 9085 features 24-bit audio processing that supports 16 AES input/output channels, 16 de-embedded channels from the HD/SD-SDI input, and eight analog audio inputs. Sixteen re-embedded channels and 16 AES output channels can be sourced from any of the inputs. Using Linear Acoustic® AEROMAX™ technology, the card applies loudness control on up to six channels of audio from any embedded, AES, or analog inputs.
AEROMAX™ algorithms use a sophisticated multiband approach to loudness processing. These algorithms can apply multifaceted loudness correction specifically targeted to various frequency ranges and other characteristics within the program material, resulting in audio free from abrupt loudness or image shifts while preserving more of the original content than previously possible. Because the card processes audio loudness locally and in sync with the video, loudness is processed without the accumulated latency delay found in other loudness processors.
Full user remote and card-edge proc control allows adjustment of audio parametric control and routing. With multiple selectable presets, several loudness processing profiles offer the best loudness processing solution for various types of program material.
9085 Options:
- Dolby® Digital AC-3 Encoding (+ENCD)
- Audio Mixing (+AMx)
- Loudness Metering (+LM-C)
- LTC In/Out (+LTC)
