Audio LTC option +LTC allows bidirectional transfer and conversion between video timecode formats and audio/RS-485 LTC. Audio LTC can be received over a selected balanced analog audio, embedded or AES input channel. Audio LTC can similarly be sent as digital audio over a selected embedded or AES output channel. RS-485 LTC can be received or sent via an RS-485 port (when card slot is correspondingly fitted with a Rear Module that accommodates RS-485).
Cards with the +LTC option can monitor video streams, RS-485 and/or selected audio channels for supported timecode formats and then select and prioritize among VBI timecode formats and audio/RS-485 LTC. Any format received by the card can be outputted as audio or RS-485 LTC. The +LTC option is available for wide range of Cobalt cards.
The software can be ordered with card purchase, or activated later using a downloadable feature key via free DashBoard™ remote control/monitoring software (no need to remove or replace card.)
Key Features
Allows full timecode compatibility between contemporary and legacy systems such as tape decks
Seamless operation using the card standard timecode selection priority and output controls
Selectable “mute” control allows for automatic muting of audio LTC if selected input format is not available.
Cobalt Options add processing versatility without the expense, complexity, space usage, or accumulated processing latency of multiple cards.
Audio LTC Diagram
