The Cobalt® ROYAL 9915DA-1×16-12G 12G/6G/3G/HD/SD-SDI 1×16 Reclocking Distribution Amplifier supports an input channel which is distributed to 16 DA outputs. The 9915DA-1×16-12G also has the option to support 1) SFP fiber Input Rx and 1) SFP fiber Output Tx.
As demand for 4K continues to rise, distribution of 12G-SDI signals within a rack-space becomes increasingly important. The 9915DA-1×16-12G allows for copper runs of up to 45 meters, reaching most equipment within a rack room or truck.
Up to 10 of the 9915DA-1×16-12G cards can be installed in a frame to provide 10 channels of input, with distribution to up to 160 coax Outputs. Full user DashBoard™ or Remote Control Panel remote control allows full status and control access locally or across a standard Ethernet network.
Key Features
Supports all popular formats: 480i, 576i, 720p, 1080i, 1080PsF, 1080p, 2160p
Full support of 12G/6G/3G/HD/SD-SDI and ASI/DVB
Input data rate auto-detection for all industry-standard data rates
One-card solution for distribution of 4K/8K content over 12G-SDI interfaces
Card display and DashBoard status input lock indicators
Hot-swappable
Five year warranty
Specifications
Note: All specifications are subject to change. Inputs/outputs are a function of rear I/O module used.
Power
<10 Watts
12G / 6G / 3G / 1.5G / 270M Serial Digital Interface Input/Output
(1) 75Ω Connector Input (max). (16) 75Ω Connectors Output (max). SDI Formats Supported: SMPTE ST2082-1,10, 424M, 292M, SMPTE 259M-C. All inputs/outputs 12G compliant and SDQS/2SI quad 3G compliant.
See product manual for all supported formats.
Coaxial Receive Performance (Cable Length; Belden 4694)
50m/70m/150m/180m (12G/6G/3G/HD)
Fiber Transmit Output (typ. with optional fiber Tx SFP)
LC connector
Fiber Wavelength, Tx: 1310 nm
Tx Power: -5.0 dBm (min)
Fiber Receive Input (typ. with optional fiber Rx SFP)
LC connector
Receive Sensitivity: -23 dBm; 1260 to 1620 nm
Receive Sensitivity: (-12G SFP models; 12G/6G/3G/HD/SD): -9/-10/-10/-10/-10 dBm
Diagrams
Block Diagram
Rear I/O Module output designations here correlate to output numbers for four DA quadrants as shown in the card block diagram. As such, SDI outputs within a quadrant group can only be sourced from a particular input at one time (for example, if the card is set to feed SDI IN A to quadrant SDI Out (1-4), the rear module outputs 1 thru 4 will all output SDI IN A). Dissimilar inputs cannot be routed within a quadrant group (for example, SDI OUT 1 sourced from SDI IN A and SDI OUT 2 sourced from SDI IN B).
All four SDI IN A thru SDI IN D are funcational only when mated to quad input card models. Dual and single card models omit SDI IN D as NC and progressively omit SDI IN C and SDI IN B as NC.
RM20-9915-A-HDBNC
- (1) SDI In (SDI IN A)
- (16) SDI Out
- (2) SFP cage access
(All coaxial connectors HD-BNC.)
RM20-9915-B
- (1) SDI Input (SDI IN A)
- (16) SDI Output
Note: Applicable only where -SFP options are offered. SFP 1 and SFP 2 details show SFP receptacle cage is included factory-installed on rear module (plug-in SFP modules are available with respective options).
Note: MPN 1144 may have reduced receive performance due to the larger IO size.
