BlueBox™ offers excellent performance, and excels to a new level of ease of use and installation practicality. The Blue Box BBG-A-TO-S can power directly via USB to get its power from video monitors or other equipment. Blue Box Analog to SDI offers CVBS SD or component SD/HD conversion to SDI using high-quality 12-bit A/D conversion, with SD line 21 closed-captioning passed onto the converted stream.
Full support of multiple analog standards such as SMPTE, Betacam™, MII, RGB, and S-video (Y/C) is provided. A stereo analog audio pair can be embedded onto embedded audio channels 1/2 with full 24-bit resolution.
Key Features
Rugged construction backed with a five-year warranty
Compact size and low weight design easily affixes directly to camera or host device chassis. Optional BBG-MB mounting bracket provides rigid, secure mounting to mounting surfaces.
Passes line 21 closed-captioning for analog-to-SD-SDI conversions
High-quality 12-bit A/D conversion of NTSC/PAL YPbPr, RGB or S-Video/CVBS SD video to SMPTE 259M or SMPTE 292M
Stereo analog audio input embedding to embedded audio pair on SDI output
Powers directly from host equipment USB or standard corded power adapter. USB power and corded adapter can be simultaneously used to provide redundant power sourcing.
2x SDI DA output
Specifications
Standards supported
SMPTE 259M, 292M
Inputs
– YPbPr, RGB, Y/C, CVBS analog video (75Ω BNCs)
– (2) analog audio (unbalanced consumer RCA)
– DC power (via USB or adapter)
Outputs
(2) SDI (75Ω BNCs)
Audio Conversion Format
48 kHz sampling, 24-bit
Power Source
Power-sourced directly from host equipment USB port. Converter can also be powered using corded AC adapter (included)
Power
5-16 VDC, 2.4 W
DC Power Connectors
USB Mini and coaxial locking connector (for use with supplied Cobalt power adapter)
Dimensions (WxHxD)
5.5” x 3” x 1” (including connector projections)
(139 x 77 x 26 mm)
Operating Temperature Range
32°F to 122°F
(0°C to 50°C)
Diagrams
Block Diagram
Note: Device includes one PS4 Power Supply (AC adapter). Power supplies listed below are for replacement or spares purposes:
• PS4 Universal Power Supply, UL/CSA. Input: 100-240V, 60/50 Hz. Output: 5 VDC @ 12 Watts
• PS5 Universal Power Supply, IEC Connector, CE/UL/CSA. Input: 100-240V, 60/50 Hz. Output: 5V, 2A (International Power Supply. Specify country of destination.)
